JCVision 50-Inch Indoor Digital Signage Display – E-LED Backlit, Wide Viewing Angle, Wall Mount Light Box for Retail & Hospitality (HD-352C)
Detalhes do produto:
| Lugar de origem: | China |
| Marca: | JCVision |
| Certificação: | CE ROHS |
| Número do modelo: | JC-50ILB |
| Documento: | JCVision 50-inch Light Box ....pdf |
Condições de Pagamento e Envio:
| Quantidade de ordem mínima: | 1 |
|---|---|
| Preço: | 600 |
| Detalhes da embalagem: | Caixa de papelão |
| Tempo de entrega: | 5-8 dias úteis |
| Termos de pagamento: | T/T |
| Habilidade da fonte: | 50 |
|
Informação detalhada |
|||
| Marca: | JCVISION | Modelo: | HD-352C |
|---|---|---|---|
| Nome do produto: | Display de caixa de luz de parede de 50" | Tamanho da tela: | 50 polegadas |
| Tipo de luz de fundo: | E-liderado | Resolução: | 1920 × 1080 (Full HD) |
| Proporção: | 16:9 | Ângulo de visão: | 89° / 89° / 89° / 89° (E/D/U/D) |
| Exibir cores: | 16,7 milhões | Brilho: | 300 ± 20 cd/m² |
| Taxa de contraste: | 1200:1 | Tempo de resposta: | 6 ms |
| Área de exibição ativa: | 1095,84 × 616,41 mm (A × V) | Chipset: | Hi3751V352F Quad Core, 1,0 GHz |
| GPU: | Mali-450 MP2 | Sistema operacional: | Android 9.0 |
| BATER: | 2GB | Armazenar: | 32 GB |
| Decodificação de vídeo: | Até 1080P a 60 Hz | Rotação da imagem: | 0° / 90° / 180° / 270° manual |
| Portas USB: | 2× USB | HDMI: | 1 × entrada HDMI |
| Ethernet: | Ethernet RJ45 100M | Wi-fi: | 2.4G (802.11b/g/n) |
| módulo 4G: | Opcional | Formatos video: | MPEG4, MPEG2, MPEG1, WMV, TS, MOV, AVI, FLASH |
| Formatos audio: | WAV, MP3, AAC | Formatos de imagem: | JPEG, PNG, BMP, GIF |
| Alto-falantes: | 2 × 8Ω 3W | Entrada de energia: | CA 100–230 V, 50/60 Hz |
| Consumo de energia: | ≤ 150 W | Peso líquido: | 18,5 kg |
| Peso bruto: | 210,8 kg | Dimensões do cartão: | 1240 × 150 × 770 milímetros |
| Instalação: | Montado na parede (paisagem / retrato) | Operação: | Uso contínuo 24 horas por dia, 7 dias por semana |
| Recursos especiais: | Plug and Play, controle remoto, tela dividida inteligente, reprodução programada | ||
| Destacar: | 50-inch indoor digital signage display,E-LED backlit wall mount light box,wide viewing angle retail display |
||
Descrição de produto
Product Name: JCVision 50-Inch Indoor Digital Signage Display – E-LED Backlit, Wide Viewing Angle, Wall Mount Light Box for Retail & Hospitality (HD-352C)
Product Description:
The JCVision 50-inch Wall Light Box (Square Edge) is a powerful indoor digital signage display built for high-impact visual communication in retail, hospitality, and corporate environments.
Its 50-inch E-LED backlit panel offers 1920×1080 Full HD resolution, 300 cd/m² brightness, 1200:1 contrast ratio, and 89° wide viewing angles (L/R/U/D), ensuring consistent image quality from every angle. The 6ms response time makes it suitable for dynamic video content.
Under the hood, the Hisilicon Hi3751V352F quad-core processor (1 GHz) and Mali-450 MP2 GPU drive the Android 9.0 operating system with 2GB RAM and 32GB onboard storage. It supports a wide range of video, audio, and image formats (MPEG4, MPEG2, MOV, AVI, JPEG, PNG, etc.) and handles 1080P video decoding.
Connectivity options include 2× USB, 1× HDMI IN, RJ100 Ethernet, and 2.4G Wi-Fi. An optional 4G module is available for remote content management. The unit supports both horizontal and vertical wall mounting, offering flexibility for digital posters, menu boards, and advertising displays.
Key Specifications:
-
Screen Size: 50 inch
-
Resolution: 1920×1080
-
Brightness: 300±20 cd/m²
-
Response Time: 6ms
-
OS: Android 9.0
-
RAM / Storage: 2GB / 32GB
-
Power: ≤150W
-
Dimensions (with wall mount): 1123.80 × 644.00 × 29.20 mm
-
Weight: 18.5 kg (net)
![]()
